Harman PF-120 User Manual

Harman® • PF-120 Owner’s Manual_R3 • 2014 -___ • 10/1428
3-90-08120c
Service Parts
PF120
Beginning Manufacturing Date: Mar 2014
Ending Manufacturing Date: Active
IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or
distributor.
Hearth and Home Technologies does not sell directly to consumers.Provide
modelnumberandserialnumberwhenrequestingservicepartsfromyourdealerordistributor.
Stocked
at Depot
ITEM Description COMMENTS PART NUMBER
1 HopperAssembly 1-10-73807A
2 HopperLidAssembly 1-10-73491A
SpringCatch Setof2 1-00-00927
Y
HopperLidCatch 2-00-72166B
Hinge,HopperLid 3-31-73325
Gasket,HopperLid 10Ft 1-00-00248
Y
Gasket,HopperThroat 3-44-677185
Y
3 FanControl/Highlimit 3-20-23139
Y
4 CombustionBlower 3-21-08639
Y
MountingPlate 1-10-73416
Grommets&Spacers Pkgof25 1-00-960026
FanBlade,43/4”SinglePaddle(CombustionBlower) 3-21-00661
Y
CombBlowerMountingScrews Pkgof100 1-00-53483208
CombBlowerHeatShield 2-00-73339
5 Filterboxkit 1-00-73421A
6 BottomCover
Front 2-00-73338-15S
Rear 2-00-73340-15S
7 AshDoor 1-10-73814-15A
8 TopCover
Front 2-00-73411-15S
Rear 2-00-73412-15S
9 ShakerCover 2-00-73335-15S
ShakerWeldment 1-10-73354
ShakerChains Setof8 1-00-003027
Gasket,Chainshaker Pkgof2 3-44-08100-2
Y
Additionalservicepartsonfollowingpage.
10/14
Pellet Furnace
1
3
2
5
6
7
8
9
4
1-90-08120
D. Service Parts
