5.2: AUX SEND OUTPUT
CHANNEL CONTROLS > AUX MASTER CONTROLS
5.2: AUX SEND OUTPUT
The Aux Master control determines the output level of a whole Aux Master mix (the sum of all
Aux/FX contributions)
Notepad-12FX Aux Bus
On Notepad 12FX, the aux bus is sent to the Lexicon effects processing before the aux master so
while the Aux/FX mix is the same, the overall level of the two destinations - aux output and effects
processing are independent.
When the OUTPUT TYPE of the aux output is set to STEREO PHONES, this control additionally
serves as a headphone level control.
Notepad-8FX Aux Bus
On Notepad 8FX, this control is in the signal path before the Lexicon effects processing so serves
as a master effect send control and therefore an effects wet/dry control as the 8FX does not have
a dedicated FX return channel. The effects are returned to the master mix at unity.
NOTEPAD 5, 8FX, 12FX User Manual
