Service Parts
TL2.6 W/Pedestal
Beginning Manufacturing Date: Sept 2011
Ending Manufacturing Date: Active
IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or
distributor.
Hearth and Home Technologies does not sell directly to consumers. Provide
model number and serial number when requesting service parts from your dealer or distributor.
Stocked
at Depot
ITEM DESCRIPTION COMMENTS PART NUMBER
1 Top load door, painted w/gasket & hdwr
Pre 008850439 1-10-856509A
Post 008850439 1-10-856009A Y
Top load door gasket 5 ft 1-00-10050 Y
Hinge Spacer Qty 2 req 2-00-40021L
Bottom Hinge Set of 2 1-00-856084
Wood Handle, Pkg of 3 Pre 008850439 3-40-08746-3
2
Top Load Door Lift Arm w/Knob Post 008850439 1-10-08722 Y
3
Wood Handle w/Hardware 2 Sets 1-00-06228
4
Damper frame asy with damper 1-10-250109A Y
Damper adjuster with hardware 1-00-249135
Damper gasket 30 ft 1-00-00888 Y
Damper Shaft Retainers & Hardware Set of 2 1-00-249145 Y
Damper, Only 1-10-249107
Gasket, 1" Single Ply Tape 10 Ft 1-00-88100 Y
5
Firedome Plus Combustion Package 3-40-358110 Y
Gasket, brick air Pkg of 4 3-44-2500202-4 Y
6
Rear brick clips with hardware Pkg of 2 1-00-249153 Y
7
Wooden handle for damper w/hardware Pkg of 2 1-00-00249 Y
8
Damper handle, painted 3-50-00500S Y
9
Damper shaft bushing plates w/hardware Inner & outer 1-00-856061 Y
10
Damper rod weldment 1-10-856011W Y
11
Left side panel, painted 2-00-857019B Y
12
Inlet brick 3-40-358112 Y
13
Brick Air Plate Set of 2 1-00-358118 Y
14
Side & rear rebrick 6 pc set 1-00-857047 Y
15
Ash grate 2-00-857052B Y
16
Andiron with hardware and extensions 1-00-856010 Y
17
Front load door asy, painted with glass 1-10-06920A
Ball Spring Bracket 2-00-06714
Cast Door, Painted 4-00-06920P
Door gasket 30 ft 1-00-00888 Y
Door latch, painted w/hdwr & handle 1-00-249119 Y
Glass clips Set of 4 2-00-05202-4 Y
Glass gasket 15 ft 1-00-2312 Y
Glass only 3-40-06932 Y
Latch plate, roller & hardware 1-00-06903
Additonal service parts on following page
