Service Parts
TL2.6 W/Pedestal
Beginning Manufacturing Date: Sept 2011
Ending Manufacturing Date: Active
IMPORTANT: THIS IS DATED INFORMATION. Parts must be ordered from a dealer or
distributor.
Hearth and Home Technologies does not sell directly to consumers. Provide
model number and serial number when requesting service parts from your dealer or distributor.
Stocked
at Depot
ITEM DESCRIPTION COMMENTS PART NUMBER
18
Ash door asy, painted with handle 1-10-856005A
Ash door latch only 3-00-249149
Ash door gasket 5 ft 1-00-10000 Y
Ash door hinge with hardware 1-00-856020
Ash door roller with hardware 1-00-06902
Ash Door Wood Handle Pkg of 3 3-40-08746-3
19
Air slide rod bracket with hardware 1-00-856008 Y
20
Air control weldment 1-10-856004W Y
21
Air slide 1-10-856003W Y
22
Ash pan 1-10-857002A Y
23
Combustion shoe brick 3-40-00100 Y
Shoe brick gasket 3-44-06951 Y
24
Side brick insulation Qty 2 req 3-40-857054 Y
25
Right side panel, painted 2-00-857021B Y
26
Heat shield mounting plate, painted 2-00-856026B
27
Rear heat shield, painted with hardware 1-00-857024 Y
Blower Blockoff 1-00-856019
Brick 12 x 6 x1 1/4 3-40-86125 Y
Brick Retainers - Side Set of 2 1-00-06945 Y
Cast Weld on Hinge Qty 2 req 3-00-773813
Combustion Package Cap 2-00-358150B Y
Distribution Blower 7000-537
Flue collar Weldment, Painted W/Gasket & Hardware
Pre 008850219 1-10-857038W Y
Post 008850219 1-10-857001W Y
Flue Opening Cover 1-00-857023
Power cord 3-20-06652 Y
Snap Disc Control 3-20-408412 Y
Top Vent Cover 1-10-857014
Touch Up Paint
Pre 008850474 3-42-1990
Post 008850474 3-42-19905
Ashlip Trim Brushed Stainless 3-43-4722386-7
Door Trim Brushed Stainless 3-43-856015-7
Tile Trim Brushed Stainless 3-43-06729-7
Spring Clips (Required for installation of Tile Frame) Pkg of 20 3-31-232547-20
Additonal service parts on following page
