C. Control Ex planation
Mode Selector
AllowsyoutochoosebetweenRoomTempMode,
StoveTempMode,orOFF.Alsoallowsyouto
varythedistributionblowerspeedbyturningthe
knobtothehighorlowsideofeachmode.
Feed adjuster
Sets the maximum feed
rate
Test
Runs all motors at full
speed for one minute to
check operation. After
a minute, the control
will simulate a minimum
burn and the combustion
blower will remain on
low.
Distribution Blower
speedadjustmentrange.
L=low
H=high
Variable speed
anywhere between L
andH; althoughas the
stovetemp.goesup,so
doestheLandHscale.
Power Light
Indicatespowertothe
control.
Indicatespowerto
the feed motor.
Indicatespowerto
combustion blower
Status Light
Will be lit in either stove
or room temp mode when
pointer is not within off
position band except after
normalshutdown.Blinksto
indicate errors listed below.
Indicatespowerto
distribution blower.
Indicatesigniterison.
Igniter switch
Set to appropriate Start-
Up mode.
Temp dial
Allows you to adjust the
room temperature in Room
TempModeusingtheouter
scale marked in degrees
Fahrenheit. It also allows
you to adjust the stove
temperaturewhileinStove
TempModeusingtheinner
scalemarkedfrom1to7.
Dealer Diagnostic Port
For dealer maintenance
only.RequiresspecialDDM
monitorsuppliedtoHarman®
Dealersexclusively.
