Harmar Mobility AL001 - Motor Covering Wiring Schematic

Outside Vehicle Lis: Owner’s Manual
06DEC19 | 630-00105 REV A
15
OUTSIDE VEHICLE LIFTS: SECTION 6
MOTOR COVER WIRING SCHEMATIC
Secon 6
Motor Cover Wiring Schemac
CIRCUIT
BREAKER
BATTERY
VEHICLE HARNESS
KEY SWITCH
LIFT
LIGHT
TRAILER PLUG
MOTOR COVER
LIGHT
ACTUATOR
POLE REVERSING
SWITCH
12 V +
