Harmar Mobility AL100-DE - Closing the Swing-Away

OUTSIDE VEHICLE LIFT: Owner’s Manual
18MAR2022 | 630-00105 B
12
OPERATION
OUTSIDE VEHICLE LIFT: SECTION 3
CLOSING THE SWING-AWAY
1. Close the Swing-Away by returning it to the
stowed position. See Figure 3-12.
Figure 3-12
2. When the Swing-Away is fully closed, the
T-handle will be fully retracted. See Figure 3-13.
Figure 3-13
3. Install the safety pin. See Figure 3-14.
Be sure to stay clear of the latching mechanism to
avoid personal injury. See Figure 3-13.
Safety Pin must be installed before transit to avoid
damage and injury. See Figure 3-14.
WARNING
!
Figure 3-14
AL105L AL105
Install
Safety Pin
