For AL030 ONLY
Bumper Mount
( Be sure to comply with
vehicle's bumper rating )
Flat Bar Style
( Be sure to comply with
vehicle's bumper rating )
Omit stabilizer
Do not attempt to
mount up from under
FOR AL030 ONLY
( Ball Mount
Hitch adapter )
Ball Mount Hitch
Adapter and
stabilizer
Ball Mount Hitch Adapter
can NOT be used when
installing a Swing Away
Swing
Away
OR
Only Class 3 or 2
Hitch Adapters
can be used with
a Swing Away
Measure from Hitch Bar to ground
5-13"
13-15"
15-17"
17-19"
Drawings below depict a Ball Mount Hitch Adapter
The installation for a Class 2 or 3 Hitch
Adapter can be used and is identical
OMIT
STABILIZER
OMIT
STABILIZER
HITCH
POST
BALL MOUNT
HITCH
ADAPTER
INSTALLATION
