Harmar Mobility AL560 - Al300

ASSEMBLY PARTS
ITEM QTY
PART NO. DESCRIPTION
1 1 201-ZA06-C INNER TUBE
2 1 202-ZA10-C OUTER TUBE
3 1 203-ZA10-C PLATFORM
4 1 204-ZA06-C EXTENDED CRADLE BAR
5 2 501-ZA06-C SPREADER BAR BRACKET
6 1 ALA10010REV2 ACUTATOR
7 1 ALA10032 ROLLER 2" DIA UHMW
8 1 ALA10050 TAB, ACTUATOR
9 1 ALA10095 STICKER, OUTSIDE LIFT
10 2 ALA11025 EXTENSION SPRING
11 1 ALA14096 RED REFLECTOR
12 1 ALA180 HARDWARE PACK
13 1 ALA50099 PATENT STICKER
14 1 ALA580 U-BOLT HARDWARE KIT
15 1 ALA58040C ANCHOR PLATE
16 1 ALA99995 LABEL, SERIAL NUMBER
17 6 BHCS-0_37-16--0_75-SS BUTTON HEAD, 3/8-16 x 0.75, SS
18 1 BHCS-0_37-16--1_00-SS-NP BUTTON HEAD 3/8-16 x 1.00 SS
19 2 BHCS-10-24--0_50-SS BUTTON HEAD, #10-24 X 0.50, SS
20 1 H10096 STICKER, PLATFORM
21 1 H11010 J-CAM
22 1 200-2A01-A MOTOR COVER ASSEMBLY
23 1 H14044 ROLLER
QTYITEM
PART NO. DESCRIPTION
ASSEMBLY PARTS
WASH-0_50-1_50--0_12-N
WASH-0_50-1_06--0_08-RH-SS
WASH-0_25-0_62--0_04-RH-SS
SPCR-0_25-0_50--0_31-N
PIN-0_50--3_00-CL-Z
PIN-0_12--1_50-CO-SS
NUT-10-24-NYLOCK-Z
NUT-0_50-13-NYLOCK-Z
NUT-0_50-13-NYLOCK-NTE-Z
NUT-0_37-16-NYLOCK-NTE-Z
NUT-0_25-20-NYLOCK-Z
HHCS-0_50-13--2_50-Z
HHCS-0_50-13--0_87-Z
HHCS-0_50-13--0_75-Z
HHCS-0_25-20--1_75-Z
HHCS-0_25-20--0_75-NP-Z
237
4
5
2
2
9
2
46
45
41
44
43
42
39
40
38
RR-0_62-EC-Z
1
1
1
RIV-188-SS
4
6
4
2
2
2
2
2
30
36
35
34
32
33
31
28
29
27
26
25
24
HWTS-14--0_75-Z
1
1
1
1
1
H50011B
H50010B
H14407
H14045
NUT, NYLOCK, 1/2-13, ZP
WASHER, FLAT, 1/2", NYLON
WASHER, FLAT, 1/2", SS
WASHER, FLAT, 1/4", SS
SPACER, 1/4", for CAM SPRINGS
E-CLIP, 5/8" SHAFT
CLEVIS PIN, 1/2" x 3" L, ZP
COTTER PIN
NUT, NYLOCK, #10-24, ZP
RIVET
THIN NUT, NYLOCK, 1/2-13, ZP
THIN NUT, NYLOCK, 3/8-16, ZP
NUT, NYLOCK, 1/4-20, ZP
HEX WASHER, #14 SELF DRILL, 0.75, ZP
HEX HEAD, 1/2-13 x 2.50, ZP
HEX HEAD, 1/2-13 X 0.88, ZP
HEX HEAD, 1/2-13 x 0.75, ZP
HEX HEAD, 1/4-20 x 1.75, ZP
HEX HEAD, 1/4-20 x 0.75, ZP
RIGHT HAND, Q-STRIANT - BLUE
LEFT HAND, Q-STRAINT - BLUE
ALUMINUM PLATE
CLEVIS PIN
29
1
32
2
34
1
42
2
6
1
8
1
10
2
28
1
39
1
1
1
2
1
21
1
3
1
22
1
23
1
24
1
40
1
43
1
45
1
44
2
45
2
45
2
7
1
18
1
25
1
46
4
41
9
9
1
33
4
16
1
20
1
12
1
11
1
38
2
27
2
26
2
31
2
36
4
14
1
4
1
5
2
19
2
13
1
15
1
17
6
37
2
30
2
35
6
EXPLODED VIEW - AL300
31
Outside Lifts - Installation & Owner’s Manual 2013
45
Section 2 : inStaller
Exploded Views
AL300
