Harobot HRB-E0110Q - Operation Instructions

Harobot
[Operation instructions]
The appearance structure of the product is shown in the following figure:
1—Infrared detector
2—LCD screen
3—Up button
4—Down button
5—Set button
6—Measuring button
7—Battery cover
Display icon description
Icon definition
Icon
State description
Measurement mode
1
Measurement mode and calibration mode display
Display value
2
Measured temperature value
Storage position
3
memory group number position
Temperature symbol
4
Centigrade
Fahrenheit degree
Buzz symbol
5
display
Buzzer on
No Display
Buzzer off
Low battery symbol
6
display
Low batter
No Display
Sufficient electricity
