APPENDIX A
16 of 17
REPLACING THE FUSES
To replace a fuse:
• Using a slotted screw driver, twist out the fuse
holder.
• Replace the fuse.
NOTE:
To install the correct fuse for a particular application refer
to the table below.
Twist the fuse holder back in place.
ACCESSORY
TEMPERATURE RANGE (°C) SLOW-BLOW HEATER FUSE
(A)
CHC LN2-600 5
DER LN2-500 8
FAS-TCC 0-200 8
FATIR Room-175 5
HPL-TC Room-260 8
HTC Room-500 15
HVC Room-600 5
RANGEIR Room-175 5
RGR Room-400 8
SEA-HLC Room-100 2
SEA-HOT Room-100 3
TFC Room-260 8
TGC Room-260 10
UNS-HOT Room-100 5
HON-FSL, FLL, FSS, FLS -10 to 190 8
Table 1 • Heater Fuses for Various Accessories
FUSE POSITION
FUSE TYPE QUANTITY
Power Outlet 2A Slow-Blow 2
XFMR 4A Slow-Blow 1
Table 2 • Additional Fuses for the Automatic Temperature Controller
