Harris HT 30CD - Page 148

472 1651 000 ...... XFMR, PWR 36V 1 OOOMA. . . . . . . . . . . . .. 1.0 EA
522 0376 000.. .... CAP 1100 UF 50V .. .. .. .. .. .. .. .. .... 2.0 EA
546 0293 000 ...... RES 2 OHM 2.5W 5% .. .. .. .. .. .. .. ... 1.0 EA
5600049000 ...... MOV 4500A 75J 275VAC ............... 1.0 EA
6101027000 ...... HEADER, MALE 12 PIN ................ 1.0 EA
8396337185 ...... SCHEM, AUX PWR SUP ............... 0.0 EA
9396337186 ...... PWB, AUX PWR SUPPLY ............ " 1.0 EA
9992416001 ...... HARDWARE LIST, PWB, AUX .......... 1.0 EA
T001
C001 C002
R001
RV001
J001
Table 7-29. PWB,SCHMITT TRIGGER 1A6A9 - 9928375001
Harris PN Descrie.tion OTY UM Reference Designators (02
3582975 000 ...... EJECTOR, PWB, STAMPED A9 . . . . . . . .. 1.0 EA
382 0774 000.. .... IC 74HC14 ESD .. .. .. .. .. .. .. ... 1.0 EA U001
384 0662 000.. .... LED RED ESD.. .. .. .. .. .. .. .. .. .. ... 1.0 EA DS001
4040674000 ...... SOCKET 14 PIN DIP (D-L) .............. 1.0 EA XU001
5160453 000 ...... CAP .1 UF 100V 20% X7R .. .. .. .. .. .... 1.0 EA C001
548 2400 242 ...... RES 267 OHM 1/2W 1 % ... . . . . . . . . . . .. 1.0 EA R003
5482400289 ...... RES 825 OHM 1/2W 1% ............... 2.0 EA R001 R002
6101035000 ...... HEADER, 14 PIN PC RIBBON ........... 2.0 EA J002 J003
839 8023 001 ...... PWB, SCHMITT TRIGGER. . . . . . . . . . . .. 1.0 EA
839 8023 002 ...... SCHEM, SCHMITT TRIGGER ........... 0.0 EA
929 9135 348 ...... CABLE, 14 COND RIBBON.. .. . . .. . .. .. 1.0 EA
Table 7-30. MIMIC BOARD 1A9 - 992 6463 002
Harris PN Descrie.tion OTY UM
3800125 000 ...... XSTR, NPN 2N4401 ESD .............. 8.0 EA
380 0126 000 ...... XSTR, PNP 2N4403 ESD .............. 8.0 EA
3820510000 ...... 'IC, ILO-74 OPTO ISOL ESD ........... 1.0 EA
3821020000 ...... IC, 4N33 OPTO-COUPLER ESD ........ 2.0 EA
3840205 000 ...... DIODE SILICON 1 N914/4148 ESD ....... 4.0 EA
Reference Designators (8)
0001 0002 0003 0004 0005 0006 0007 0008
00090010001100120013001400150016
U001
U003 U004
CR005 CR006 CR007 CR008
3840787000 ...... LED, RED/GRN, RECTANGULAR ESD .. 26.0 EA DS001 DS002 DS003 DS004 DS005 DS006 DS007 DS008 DS009 DS014
DS015 DS016 DS017 DS018 DS019 DS020 DS021 DS022 DS023 DS024
DS025 DS026 DS027 DS028 DS029 DS033
384 0807 000. . . . .. LED YELLOW 2 X 5MM ESD . . . . . . . . . .. 1.0 EA
540 1370 000.. .... RES NETWORK 220 OHM 2% .......... 2.0 EA
540 1373000 ...... RES NETWORK 680 OHM 2% . . . . . . . . .. 1.0 EA
540 1443000 ...... RES NETWORK 27 OHM 2% ........... 2.0 EA
5401444000 ...... RES NETWORK 150 OHM 2% .......... 2.0 EA
548 2400 189. . . . .. RES 82.5 OHM 1/2W 1 % ............... 2.0 EA
548 2400 289 ...... RES 825 OHM 1/2W 1 % ............... 4.0 EA
5482400301 ...... RES 1K OHM 1/2W 1% ................ 1.0 EA
548 2400 305.. .... RES 1.1 K OHM 1/2W 1 %.. .. .. .. .. .. ... 2.0 EA
5482400309 ...... RES 1.21 K OHM 1/2W 1 % .............. 1.0 EA
5482400401 ...... RES 10K OHM 1/2W 1% ............... 1.0 EA
5482400601 ...... RES 1MEG OHM 1/2W 1% ............. 2.0 EA
6041111000 ...... SW PB GRAY MOM W/O LED ........... 1.0 EA
604 1112 000 ...... SW PB GRAY MOM W/GRN LED ........ 2.0 EA
604 1122 000 ...... SW PB GRAY MOM WIRED LED. . . . . . .. 1.0 EA
6100829 000 ...... HEADER, 60 PIN PC RIBBON. . . . . . . . . .. 1.0 EA
6101001000 ...... HDR, 10 PIN RTANG .................. 1.0 EA
8396337181 ...... SCHEM, MIMIC PANEL. ............... 0.0 EA
8435191 001 ...... PCB, MIMIC PANEL. .................. 1.0 EA
DS032
R001 R002
R007
R003
R004
R005
R006
R013
R014
R009 R010
R011 R012
R016
R017 R018
R015
R008
R019
R020
S001
S002 S003
S004
J001
J002
