Harris HT 30CD - Page 151

4040303000 ..... SOCKET IC 10 PIN ................... 2.0 EA
4721578000 .... , XFMR, PWR 24V 100MA .............. 1.0 EA
4940218000 ..... CHOKE WIDE BAND .................. 2.0 EA
5000833000 ..... CAP, MICA, 390PF 500V 5% ........... 2.0 EA
5000835000 .... , CAP, MICA, 470PF 500V 5% ........... 2.0 EA
5060232000 ..... CAP .01UF 100V 5% .................. 2.0 EA
506 0233 000 .. ... CAP.1 UF 63V 5%.. .. .. .. .. .. .. .. .... 2.0 EA
5160054000 ..... CAP, DISC .001UF 1KV 10% ........... 4.0 EA
522 0573 000 .... , CAP 47UF 63V 20% . . . . . . . . . . . . . . . . .. 2.0 EA
526 0049 000 . . . .. CAP 6.8UF 35V 20%. . . . . . . . . . . . . . . . .. 2.0 EA
5260318000 ..... CAP 10UF 35V 20% .................. 2.0 EA
5482400201 ..... RES 100 OHM 1/2W 1% ............... 2.0 EA
548 2400 281 ..... RES 681 OHM 1/2W 1 % .. .. . . .. .. . .. .. 2.0 EA
5482400301 ..... RES 1 K OHM 1/2W 1 %.. .. .. .. .. .. .... 2.0 EA
5500935000 ..... POT 2K OHM 1/2W 10% ............... 2.0 EA
6101038000 ..... CONN 12 PIN RT ANGLE PC ........... 1.0 EA
8396337207 . . . .. PWB, CURRENT MONITOR 1A4 ........ 1.0 EA
8396337208 .... , SCHEM, CURRENT MONITOR. . . . . . . .. 0.0 EA
9992431 001 ..... HARDWARE LIST.. .. .. . .. . .. .. .. .... 1.0 EA
XU003 XU004
TOO 1
L001 L002
C005 C006
C012 C014
C007 C008
C003 C004
C015 C016 C017 C018
C001 C002
C011 C013
C009 C010
R005 R006
R007 R008
R003 R004
R001 R002
J001
Table 7-36. AC PH LOSS DET/MON-1A12 - 9926846001
Harris PN Description QTY UM Reference Desig!}2.
tors
Jt:J~_," ___ ~._
3583055000 . . . .. FIXING FLANGE, HORZ. 231 . . . . . . . . . .. 2.0 EA #J001
382 0719 000 .... , IC LM324AN ESD . . . . . . . . . . . . . .. 1.0 EA U003
3840431 000 . .... RECT. 1 N4001 ESD.................. 3.0 EA CR001 CR002 CR003
3840661 000 .... , LED, GRN, T 1-3/4, RT ANG ESD....... 1.0 EA DS001
4721310000 ..... XFMR, PWR 24V 100MA .............. 3.0 EA T001 T002 T003
4940218000 ..... CHOKE WIDE BAND .................. 1.0 EA L001
5000833000 . . . .. CAP, MICA, 390PF 500V 5% . . . . . . . . . .. 3.0 EA C005 C006 C007
516 0054 000 . .... CAP, DISC .001 UF 1 KV 10% .. .. .. .. . .. 6.0 EA C012 C013 C014 C015 C016 C017
5160453000 ..... CAP .1UF 100V 20% X7R .............. 1.0 EA C008
5220548000 ..... CAP 10UF 50V 20% .................. 1.0 EA C004
526 0049 000 .. ... CAP 6.8UF 35V 20%.. .. .. .. .. .. .. .... 3.0 EA C009 C010 C011
5260358000 ..... CAP 22UF 35V 10% .................. 3.0 EA C001 C002 C003
5482400301 ..... RES 1 K OHM 1/2W 1 %.. .. .. .. .. .. .... 1.0 EA R030
5482400401 ..... RES 10K OHM 1/2W 1% ............... 3.0 EA R001 R004 R007
5482400451 ..... RES 33.2K OHM 1/2W 1% ............. 6.0 EA R002 R005 R008 R024 R025 R026
6101005000 .... , PLUG, SHORTING .040 PINS ........... 3.0 EA P002 P003 P004
6101027000 ..... HEADER, MALE 12 PIN ............... 1.0 EA J002
610 1039 000 .. ... CONN 16 PIN RT ANGLE PC ........ '" 1.0 EA J001
8396337220 . . . .. SCHEM, AC PH LOSS DET/MON. . . . . . .. 0.0 EA
9396337221 ..... PWB, AC PH LOSS DET/MON . . . . . . . . .. 1.0 EA
9992444001 ..... HARDWARE LIST. . . . . . . . . . . . . . . . . . .. 1.0 EA
Table 7-37. PREAMP PWR MONITO-1A13 - 992 6873 001
Harri~pN _" __ ,,.,..J2!!.scrie!l~~_,.~._,_,~. __ "" ____ gTY UJ:~!._._~ren<?f!. Desi~!}atq!.~J~ ___ " ____ • __ , __ " __ _
448 0875 000 .. ... BOX SHIELDED .. .. .. .. .. .. .. .. .. ... 1.0 EA
8396337217 . . . .. SCHEM, PREAMP PWR MONITOR. , . . .. 0.0 EA
9926874001 ..... PWR MONITOR BD-1A13A1 ........... 1.0 EA A001
Rev.M1: 9-17-02 888-2385-001
7-31
WARNING: Disconnect primary power prior to servicing.
