RF-5800H 125-WATT COMMUNICATION SYSTEM
GENERAL INFORMATION
1-6
Figure 1-3. Relationship of Units in RF-5800H 125-Watt Vehicular System
Typical Configuration
RF-5800H-MP MANPACK
RADIO
RF-5071VSM
VEHICULAR SHOCK
MOUNT
GND
J9J8 J10
D.C. POWERCPLR CONTROLPA CONTROL
J12
RF IN
J11
RF OUT
RF-5211VSM
VEHICULAR SHOCK
MOUNT
RF-5832H-PA 125-WATT
POWER AMPLIFIER
5800H-125-VEH6
CB1
