HART HLED01 - Features

6 – English
FEATURES
KNOW YOUR PRODUCT
See Figure 1.
The safe use of this product requires an understanding of
the information on the tool and in this operator’s manual as
wellasaknowledgeoftheprojectyouareattempting.Before
use of this product, familiarize yourself with all operating
featuresandsafetyrules.
DEPTH ADJUSTMENT KNOB
The depth adjustment knob allows user to control the depth
ofcut.Adjustthebladedepthfrom1/2in.to2in.
DROP WHEEL LEVER
Thedropwheeladjustmentleverenablesedgingatmulti
levelareaslikecurbs.
EDGE GUIDE LEVER
Theedgeguidelevercontrolsthedepthoftheedgeguard.
GUARD SWEEP
Theguardsweep removes clippings anddebris fromthe
bladearea.
LOCK-OUT
Thelock-outpreventsaccidentalstarting.
PRODUCT SPECIFICATIONS
Motor ..................................................................................................................................................................... 40 Volts DC
Blade Length.................................................................................................................................................................. 8.5in.
Edging Depth............................................................................................................................Adjustablefrom1/2in.to2in.
SYMBOLS
Some of the following symbols may be used on this product. Please study them and learn their meaning. Proper
interpretation of these symbols will allow you to operate the product better and safer.
SYMBOL NAME DESIGNATION/EXPLANATION
n
o
No Load Speed
Rotational speed, at no load
.../min
Per Minute
Revolutions,strokes,surfacespeed,orbitsetc.,perminute
V
Volts
Voltage
Hz
Hertz
Frequency (cycles per second)
min
Minutes
Time
