12. Technical Data
The Bari, certifi ed in compliance with DIN-EN 13240 : 2001 + A2 2004 and Art. 15 a
B-VG (Austria), can only be operated when the fi re box is closed; more than one device
can be connected to the chimney.
VKF-No.: 14262; Inspection Report No. (A): FSPS- WA 2005-A
The following data applies to the chimney characteristics in accordance with EN 13384-1 / 2
Combustion Values Wood Briquette
Nominal Thermal Output 6 6 kW
Waste Gas Mass Flow Rate 5,5 5,5 g/s
Waste Gas Outlet Temp. 320 320 ˚C
Min. Supply Pressure at Nominal Thermal Output 12 12 Pa
CO content at 13% O2 1104 882 mg/m³
Effi ciency 80 79 %
Particulate 13 26 mg/m³
Depending on the insulation of the building, the nominal thermal output of 6 kW indicated
on 20 - 80 m² (subject to change)
Dimensions: Height Width Depth
Stove 107,5 / 111,5 / 112 cm 48 cm 48 cm
Fire box 43 cm 28 cm 30 cm
Steel Ceramic Soapstone
Weight 146 kg 165 kg 205 kg
140 kg with ceramic
154 kg with soapstone
Fire Box Opening: 1185 cm²
Flue pipe diameter: 15 cm
Pipe diameter of Hase ventilation system* 10 cm
Rotating system not applicable if Hase ventilation system is used!
* For separate air supply in low-energy houses
and insuffi cient combustion air supply in the
room where the stove is installed
Dimensions in cm
Stove‘s angle of rotation: 360° ·
Can be stopped in place and locked right/left
in 15° gradients.
Observe safety distances to
combustible or fl ammable materials!
Front view Side view
Top view
Ø 48
24
Stove height: max. 112
Connection height : 105
Connection height of Hase ventilation system: 11
