Hasselblad 503CW Service Manual

Description
Pos
No.
Pcs Spare
Part No.
Remark
Camera body 503CW
8
May 2000
Revision 2
1 1 30 324 Gear housing Complete
2 1 830 060 Screw
3 1 820 415 Screw
4 1 22 767 Coupling
5 1 22 799 Washer Alternatively 2 pcs
6 2 820 020 Screw
7 1 816 507 Spring
8 1 13 170 Adjustable pawl
9 1 820 019 Screw
10 1 20 924 Ratchet wheel
11 1 810 840 Washer
12 1 30 304 Gear housing, front
13 1 13 169 Gear
14 1 812 106 Pin
15 1 816 504 Spring
16 1 20 919 Hook
17 1 810 826 Washer
18 1 810 938 Locking ring
19 1 13 509 Stop gear
20 1 13 157 Gear housing, rear
21 1 22 355 Mirror cam
22 1 821 033 Screw
23 1 815 707 Spring New type of winding crank from
24 1 815 904 Spring camera serial No. 19EU11514
25 1 103 516 Washer
26 1 412 105 Crank bayonet
27 3 826 401 Screw
28 1 412 323 Crank support
29 1 412 104 Crank arm
30 1 103 514 Slide
31 1 812 301 Pin
32 1 22 683 Rubber plug

Hasselblad 503CW Specifications

General

Camera Type	Medium format SLR
Exposure Modes	Manual
Focus	Manual focus
Lens Mount	Hasselblad V mount
Shutter Type	Focal-plane shutter
Flash Sync	1/90 sec
Metering	External metering required
Viewfinder	Interchangeable viewfinders (waist-level, prism)
Shutter Speed	1 sec to 1/500 sec, Bulb
Flash Sync Speed	1/90 sec
