Hasselblad 503CW Service Manual

Tools
Camera body 503CW
October 1996
Revision 0
Tool No. Description Used for
2:1
V-2200 Bender Signal arm adjustment
V-2201 Bender Mirror arm adjustment
V-2202 Bender S-arm adjustment
V-2203 Bender Release arm adjustment (aux. shutter)
V-2205 Bender Supporting tool when using V-2201
V-2206 Winding knob Substitutes regular winding crank during
repair work
V-2211 Pin driver Fitting the locating pin in the front plate
and the front gear bracket
V-2224 Bender Release arm adjustment
V-2229 Focal length gauge Adjustment of the focal length,
mirror 45ºangle and focusing screen
V-2236 Microscope Focusing screen adjustment
V-2354 Exposure gauge Release sequence control
V-4151/52 Focusing tester Focusing screen adjustment
V-4704 Key Focusing screen adjustment
V-4705 Focusing screen adapter Focusing screen adjustment

Hasselblad 503CW Specifications

General

Camera Type	Medium format SLR
Exposure Modes	Manual
Focus	Manual focus
Lens Mount	Hasselblad V mount
Shutter Type	Focal-plane shutter
Flash Sync	1/90 sec
Metering	External metering required
Viewfinder	Interchangeable viewfinders (waist-level, prism)
Shutter Speed	1 sec to 1/500 sec, Bulb
Flash Sync Speed	1/90 sec
