Hasselblad 503CW Service Manual

Description
Pos
No.
Pcs Spare
Part No.
Remark
Camera body 503CW
9
May 1997Revision 1
1 1 822 605 Screw
2 1 810 836 Washer
3 1 22 287 Damping ring
4 1 14 280 Lid
5 1 14 278 O-ring
6 1 30 384 Spring
7 1 22 699 Gear
8 1 810 953 Washer (0.3 mm)
9 1 820 015 Screw
10 1 823 015 Screw
11 1 21 125 Mechanism plate
12 1 13 182 Gear
13 1 810 404 Washer (0.3 mm)
14 1 816 802 Spring
15 1 817 112 Clip
16 1 821 631 Screw
17 1 810 532 Washer
18 1 13 112 Gear
19 1 810 826 Washer (0.10 mm) For adjustment 810 827 (0.20 mm)
20 1 20 912 Stop bar
21 1 22 436 Aux. shutter stop
22 1 821 017 Screw
23 1 13 432 Stop angle
24 1 821 032 Screw
25 1 816 914 Spring
26 1 840 701 Hub
27 1 21 167 S-arm
28 1 814 826 Spring
29 1 13 357 Release arm
30 1 22 369 Push rod
31 1 817 119 Clip
32 1 22 769 Stop lever
33 1 816 752 Spring
34 2 820 016 Screw
35 1 13 171 Bearing bracket
36 1 13 116 Fixing plate
37 1 13 167 Gear
38 1 21 125 Mechanism plate From serial No. 19ET10850
39 1 810 729 Washer (0.5 mm) "
40 1 810 705 Washer (0.2 mm) "
41 1 817 119 Clip "
-1
-1

Hasselblad 503CW Specifications

General

Camera Type	Medium format SLR
Exposure Modes	Manual
Focus	Manual focus
Lens Mount	Hasselblad V mount
Shutter Type	Focal-plane shutter
Flash Sync	1/90 sec
Metering	External metering required
Viewfinder	Interchangeable viewfinders (waist-level, prism)
Shutter Speed	1 sec to 1/500 sec, Bulb
Flash Sync Speed	1/90 sec
