Hasselblad 503CW Service Manual

Description
Pos
No.
Pcs Spare
Part No.
Remark
Camera body 503CW
10
September 1999
Revision 1
1 1 30 300 Rear plate, complete State serial No.
2 1 40 237 Rear plate State serial No.
3 1 816 805 Spring
4 1 816 804 Spring
5 1 13 125 Light trap
6 2 821 203 Screw
7 2 13 397 Foam plastic strip
8 4 810503 Washer (0.10 mm) For adjustment 810 505 (0.20 mm)
9 4 840 514 Hub
10 4 825 661 Screw
11 1 30 770 Mirror frame Incl. reflection protector 22 874
12 1 22 419 Reflection protector
13 1 90 711 Top flap
14 1 90 712 Bottom flap
15 1 22 420 Reflection protector
16 2 13 185 Lever
17 2 811 108 Pin
18 1 13 100 Connecting rod
19 1 13 101 Connecting rod
20 1 22 423 Magazine hook
21 2 823 640 Screw
22 1 22 775 Mirror
23 1 22 776 Light trap
24 1 22 804 Spring
25 1 22 819 Magnet
26 1 22 878 Arm Incl. reflection protector 22 875
27 1 810 649 Washer
28 1 22 800 Sleeve
29 3 817 115 Clip
30 1 22 779 Driving arm
31 1 22 875 Reflection protector
32 1 22 874 Reflection protector

Hasselblad 503CW Specifications

General

Camera Type	Medium format SLR
Exposure Modes	Manual
Focus	Manual focus
Lens Mount	Hasselblad V mount
Shutter Type	Focal-plane shutter
Flash Sync	1/90 sec
Metering	External metering required
Viewfinder	Interchangeable viewfinders (waist-level, prism)
Shutter Speed	1 sec to 1/500 sec, Bulb
Flash Sync Speed	1/90 sec
