Hasselblad 503CW Service Manual

Description
Pos
No.
Pcs Spare
Part No.
Remark
Camera body 503CW
11
September 1999Revision 2
1 1 30 777 Front bayonet plate Complete
2 1 40 403 Front bayonet plate
3 1 30 383 Front gear
4 1 30 386 Governor
5 2 820 014 Screw
6 1 821 009 Screw
7 1 820 018 Screw
8 1 812 202 Pin
9 2 823 440 Screw
10 1 105 107 Cover plate
11 1 810 409 Spacer
12 1 816 858 Spring
13 1 103 440 Lens catch
14 1 22 832 Foil, left
15 1 22 829 Foil, right
16 1 13 213 Foam plastic strip
17 1 13 212 Foam plastic strip
18 1 836 107 Stop pin
19 1 21 096 Plate spring Replaced by p/n 22850, page 7
20 1 820 015 Screw
21 8 820 425 Screw
22 4 103 439 Bayonet flange
23 1 812 213 Pin
24 1 823 019 Screw
25 1 103 773 Teflon button
26 1 22 876 Cover Incl. reflection protector 22 873
27 1 821 031 Screw
28 2 823 655 Screw
29 12 820 015 Screw
30 1 22 582 Foam plastic pad
31 1 22 812 Frame, complete
32 4 21 606 Screw
33 1 22 467 Light pipe
34 1 22 655 Foam plastic strip
35 1 825 420 Screw
36 4 821 017 Screw
37 1 22 828 Foam plastic strip
38 1 22 873 Reflection protector

Hasselblad 503CW Specifications

General

Camera Type	Medium format SLR
Exposure Modes	Manual
Focus	Manual focus
Lens Mount	Hasselblad V mount
Shutter Type	Focal-plane shutter
Flash Sync	1/90 sec
Metering	External metering required
Viewfinder	Interchangeable viewfinders (waist-level, prism)
Shutter Speed	1 sec to 1/500 sec, Bulb
Flash Sync Speed	1/90 sec
