Hasselblad 503CW Service Manual

Description
Pos
No.
Pcs Spare
Part No.
Remark
Camera body 503CW
12
September 1999
Revision 1
1 1 30 686 Bottom plate
2 1 30 375 Release bar
3 1 814 512 Spring
4 1 22 717 Signal arm
5 1 814 603 Spring
6 1 21095 Inner wall, right
7 1 817 119 Clip
8 6 820 014 Screw
9 1 13 356 Mirror catch
10 1 816 720 Spring
11 1 30 727 Cover
12 1 814 827 Spring
13 1 22 532 Rubber plug
14 1 13 280 Lens lock
15 1 13 362 Mirror lever
16 1 30 775 Spring
17 2 829 425 Screw
18 1 22 872 Reflection protector
19 1 22 813 Cover
-01
-01

Hasselblad 503CW Specifications

General

Camera Type	Medium format SLR
Exposure Modes	Manual
Focus	Manual focus
Lens Mount	Hasselblad V mount
Shutter Type	Focal-plane shutter
Flash Sync	1/90 sec
Metering	External metering required
Viewfinder	Interchangeable viewfinders (waist-level, prism)
Shutter Speed	1 sec to 1/500 sec, Bulb
Flash Sync Speed	1/90 sec
