June 1998
Camera body 503CW
General description
1:1
Revision 1
Camera type: Single lens reflex camera with 6 x 6 (2 1/4 x 2 1/4 in) max.
film size. Interchangeable lenses, film magazines, viewfinders
and focusing screens.
Weight: 610 g.
Lens mount: Hasselblad bayonet mount for CF and C lenses.
External
dimensions: 91L x 114W x 110H (3 9/16 x 4 1/2 x 4 11/32 in).
*Acute-Matte D designed by Minolta
Design: Mechanical, with an aluminium alloy camera body shell cast in
one piece.
Viewfinders: Folding focusing hood interchangeable with reflex viewfinder,
prism viewfinders with or without built-in exposure meter or
magnifying hoods.
Film advance: Manual advance or motor driven with Winder CW.
Simultaneous shutter cocking.
Winder CW winding time: 1.05 sec, approx. 0.8 frames/sec
in continuous mode.
Flash control: TTL/OTF-metering. ISO 16 - 1000 with flash adaptors
SCA390 or SCA590 for connection with flash units from the
SCA300 or SCA500 systems respectively. Metering area within
40 mm diameter in the centre of the image area.
Note! From camera serial No. 19ER18271 the ISO range is
changed to 64 - 4000.
Tripod coupling: 1/4 in and 3/8 in socket threads and base plate for quick
coupling attachments.
Focusing screen: Hasselblad Acute-Matte D* focusing screen.
Sales code No. 42204.
