Hasselblad 503CW Service Manual

Description
Pos
No.
Pcs Spare
Part No.
Remark
Camera body 500C/M (Classic)
18:1
October 1996Revision 0
1 1 40 309 Shell, complete (chrome) Part No. 40308 (black)
2 1 103 506 Leather
3 1 103 327 Support
4 1 103 503 Leather
5 1 20 948 Socket
6 1 13 418 Plate spring
7 1 13 417 T-arm
8 1 816 759 Spring
9 1 821 206 Screw
10 1 13 134 Release button
11 1 22 367 Buffer
12 1 13 137 Screw
13 1 103 511 Leather
14 1 103 592 Leather
15 1 103 529 Accessory rail
16 1 14 188 Name plate
402 347 Tripod socket 3/8" Standard
17 1 103 846 Tripod socket 1/4" Optional
1
18 2 824 701 Screw
19 8 823 735 Screw
20 2 823 781 Screw
21 1 103 349 Slide
Spare parts not listed are the same as for 503CW

Hasselblad 503CW Specifications

General

Camera Type	Medium format SLR
Exposure Modes	Manual
Focus	Manual focus
Lens Mount	Hasselblad V mount
Shutter Type	Focal-plane shutter
Flash Sync	1/90 sec
Metering	External metering required
Viewfinder	Interchangeable viewfinders (waist-level, prism)
Shutter Speed	1 sec to 1/500 sec, Bulb
Flash Sync Speed	1/90 sec
