SPECIFICATIONS
GRAL-XXD MODELS-
ELECTRICAL RATING CHART
GRAHL-XXD MODELS-
ELECTRICAL RATING CHART
The electrical information in the shaded area pertains to Export Models only.
• 100 and 120 volt models with infinite switch may require tandem (end-to-end) elements, consult factory for applications.
†Glo-Ray models 108" through 144" and 100 and 120 volt models of GRAL-84 and GRAL-96 contain tandem (end-to-end)
elements that may be individually controlled.
100 and 120 volt models may require additional switches, consult factory for applications.
CE approved units for 220-230 volt utilize a 220 volt heating system; 230-240 CE units utilize a 240 volt heating system.
*Not available in 100 or 120 volts.
NOTE: GRAL & GRAHL Models that have multiple voltages listed, such as 120/208, 120/240 or 100/200, have multiple circuits. For example a 120/208 volt
unit utilizes 120 volts for light circuit and 208 volts for the heat circuit(s). Consult Electrical Diagram supplied with the unit for specific information.
CAUTION - Strip Heaters with incandescent lights that require a circuit breaker larger than 20 amps must have
a separate circuit breaker for the incandescent lights that is 20 amps or less.
Model GRAL-18D
Watts: 620 Shipping Weight: 14 lbs. (6 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps 5.2 3.4 3.1 6.2 3.7 2.8 2.6
Model GRAL-24D
Watts: 820 Shipping Weight: 16 lbs. (7 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps 6.8 4.4 3.9 8.2 4.7 3.7 3.4
Model GRAL-30D
Watts: 1020 Shipping Weight: 19 lbs. (9 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps 8.5 5.3 4.8 10.2 5.7 4.6 4.3
Model GRAL-36D
Watts: 1330 Shipping Weight: 22 lbs. (10 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps 11.1 7.0 6.3 13.3 7.6 6.0 5.5
Model GRAL-42D
Watts: 1530 Shipping Weight: 25 lbs. (11 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps 12.8 8.0 7.1 15.3 8.6 7.0 6.4
Model GRAL-48D
Watts: 1840 Shipping Weight: 29 lbs. (13 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps 15.3 9.7 8.7 18.4 10.4 8.4 7.7
Model GRAL-54D
Watts: 2090 Shipping Weight: 33 lbs. (15 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps 17.4 10.9 9.7 20.9 11.7 9.5 8.7
Model GRAL-60D
Watts: 2400 Shipping Weight: 37 lbs. (17 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps 20.0 12.6 11.3 24.0 12.9 10.9 10.0
Model GRAL-66D
Watts: 2620 Shipping Weight: 40 lbs. (18 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps 21.8 13.7 12.2 26.2 14.6 11.9 10.9
Model GRAL-72D
Watts: 2910 Shipping Weight: 42 lbs. (19 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps 24.3 15.3 13.6 29.1 16.4 13.2 12.1
Model GRAL-84D
•
Watts: 3420 Shipping Weight: 47 lbs. (21 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps 28.5 17.9 16.0 34.2 19.2 15.5 14.3
Model GRAL-96D
•
Watts: 3930 Shipping Weight: 56 lbs. (25 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps 32.8 20.6 18.4 39.3 22.1 17.9 16.4
Model GRAL-108D
†
Watts: 4240 Shipping Weight: 64 lbs. (29 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps 35.3 22.3 19.9 42.4 23.9 19.3 17.7
Model GRAL-120D
†*
Watts: 4800 Shipping Weight: 72 lbs. (33 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps -- 25.2 22.5 --- 27.0 21.8 20.0
Model GRAL-132D
†*
Watts: 5300 Shipping Weight: 79 lbs. (36 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps --- 27.8 24.8 --- 29.8 24.1 22.1
Model GRAL-144D
†*
Watts: 5820 Shipping Weight: 86 lbs. (39 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps --- 30.5 27.3 --- 32.7 26.5 24.3
Model GRAHL-18D
Watts: 820 Shipping Weight: 14 lbs. (6 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps 6.8 4.4 3.9 8.2 4.7 3.7 3.4
Model GRAHL-24D
Watts: 1120 Shipping Weight: 16 lbs. (7 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps 9.3 5.8 5.2 11.2 6.2 5.1 4.7
Model GRAHL-30D
Watts: 1440 Shipping Weight: 19 lbs. (9 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps 12.0 7.3 6.5 14.4 7.8 6.5 6.0
Model GRAHL-36D
Watts: 1780 Shipping Weight: 22 lbs. (10 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps 14.8 9.2 8.2 17.8 9.8 8.1 7.4
Model GRAHL-42D
Watts: 2080 Shipping Weight: 25 lbs. (11 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps 17.3 10.6 9.4 20.8 11.3 9.5 8.7
Model GRAHL-48D
Watts: 2440 Shipping Weight: 29 lbs. (13 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps 20.3 12.6 11.2 24.4 13.4 11.1 10.2
Model GRAHL-54D
Watts: 2740 Shipping Weight: 33 lbs. (15 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps 22.8 14.0 12.4 27.4 14.9 12.5 11.4
Model GRAHL-60D
Watts: 3100 Shipping Weight: 37 lbs. (17 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps 25.8 16.0 14.2 31.0 17.0 14.1 12.9
Model GRAHL-66D•
Watts: 3420 Shipping Weight: 39 lbs. (18 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps 28.5 17.5 15.5 34.2 18.6 15.5 14.3
Model GRAHL-72D•
Watts: 3810 Shipping Weight: 42 lbs. (19 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps 31.8 19.6 17.4 38.1 20.9 17.3 15.9
Model GRAHL-84D
†
Watts: 4520 Shipping Weight: 47 lbs. (21 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps 37.7 23.2 20.6 45.2 24.7 20.5 18.8
Model GRAHL-96D
†
Watts: 5280 Shipping Weight: 56 lbs. (25 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps 44.0 27.1 24.0 52.8 28.8 24.0 22.0
Model GRAHL-108D
†
Watts: 5540 Shipping Weight: 64 lbs. (29 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps 46.2 28.5 25.3 55.4 30.4 25.2 23.1
Model GRAHL-120D
†*
Watts: 6200 Shipping Weight: 72 lbs. (33 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps --- 31.9 28.3 --- 34.0 28.2 25.8
Model GRAL-132D
†*
Watts: 6900 Shipping Weight: 79 lbs. (36 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps --- 35.5 31.5 --- 37.8 31.4 28.8
Model GRAL-144D
†*
Watts: 7620 Shipping Weight: 86 lbs. (39 kg)
Voltage 120 120/208 120/240 100 100/200 220 240
Amps --- 39.2 34.8 --- 41.7 34.6 31.8
