SPECIFICATIONS
6 Form No. TMCEM-0404
DIMENSIONS – TM-5H & TM-10H MODELS
PLUG CONFIGURATIONS
Units are supplied from the factory with an electrical cord and plug
installed. Plugs are supplied according to the applications. See 2 .
WARNING
Plug unit into a properly grounded electrical outlet
of the correct voltage, size and plug configuration. If the plug
and receptacle do not match, contact a qualified electrician
to determine the proper voltage and size and install the proper
electrical outlet.
WARNING
To prevent any injury or damage do not pull unit
by power cord.
WARNING
To prevent any injury, discontinue use if power cord is frayed
or worn.
Width Width Depth Depth Leg Height Height
Model (A) (B) (C) (D) (E) (F)
TM-5H 289 mm 187 mm 416 mm 203 mm 102 mm 387 mm
(11-3/8") (7-3/8") (16-3/8") (8") (4") (15-1/4")
TM-10H 368 mm 264 mm 416 mm 203 mm 102 mm 387 mm
(14-1/2") (10-3/8") (16-3/8") (8") (4") (15-1/4")
Shaded area reflects export models only.
ELECTRICAL RATING CHART – TM-5H MODELS
Model Voltage Hertz Watts Amps Plug Configuration Shipping Weight
TM-5H 220-240 (CE) 50/60 1340-1595 6.1-6.6 See Note 16 kg (36 lbs.)
ELECTRICAL RATING CHART – TM-10H MODELS
Model Voltage Hertz Watts Amps Plug Configuration Shipping Weight
TM-10H 220-240 (CE) 50/60 1940-2300 8.8-9.6 See Note 19 kg (41 lbs.)
NOTE: TM-5H 220-240 Volt (CE) is available with either CEE 7/7 Schuko or BS 1363.
See Plug Configurations for details.
Shaded area reflects export models only.
NOTE: TM-10H 220-240 Volt (CE) is available with either CEE 7/7 Schuko or BS 1363.
See Plug Configurations for details.
