Hatco Toast-Qwik TQ-405 User Manual

2
Form No. TQ2M-1219
English
INTRODUCTION
Hatco Toast-Qwik
®
Conveyor Toasters are specially designed
to accelerate the toasting operation. Products for toasting pass
through a heating chamber for rapid and thorough toasting.
Moisture, sugar content, and thickness of bread product effect
the ability to achieve the perfect toasted product. Conveyor
speed and temperature determine the toasting color.
Hatco toasters are built with quality to meet the demands
of foodservice operations and provide years of trouble-free
performance. The metal-sheathed tubular heating elements
are guaranteed against breakage and burnout for two years.
Hatco Toast-Qwik Conveyor Toasters are products of extensive
research and field testing. The materials used were selected
for maximum durability, attractive appearance and optimum
performance. Every unit is thoroughly inspected and tested
prior to shipment.
This manual provides the installation, safety, and operating
instructions for Toast-Qwik Conveyor Toasters. Hatco
recommends all installation, operating, and safety instructions
appearing in this manual be read prior to installation or
operation of a unit.
Safety information that appears in this manual is identified by
the following signal word panels:
WARNING
WARNING indicates a hazardous situation which, if not
avoided, could result in death or serious injury.
CAUTION
CAUTION indicates a hazardous situation which, if not
avoided, could result in minor or moderate injury.
NOTICE
NOTICE is used to address practices not related to
personal injury.
Important Owner Information ..............................................2
Introduction ...........................................................................2
Important Safety Information ..............................................3
Model Descriptions ..............................................................4
Model Designation ...............................................................5
Specifications .......................................................................6
Plug Configurations .............................................................6
Electrical Rating Charts ....................................................... 6
Dimensions .......................................................................... 8
Installation ...........................................................................10
General .............................................................................. 10
Front or Rear Discharge Installation ................................. 11
Operation .............................................................................12
General .............................................................................. 12
Operating Model TQ-10 .....................................................12
Operating TQ-400, -800, -1200, and -1800 Series ...........13
Power Save Mode with Indicator Light ..............................14
Adjusting the Toast Feed Ramp ........................................14
Maintenance ........................................................................15
General .............................................................................. 15
Daily Cleaning ...................................................................15
Cleaning the Toast Feed Ramp .........................................15
Cleaning the Bottom Element Reflector ............................15
Troubleshooting Guide ......................................................16
Options and Accessories ..................................................17
Limited Warranty ................................................................18
Authorized Parts Distributors ...........................Back Cover
IMPORTANT OWNER INFORMATION
Record the model number, serial number, voltage, and
purchase date of the unit in the spaces below (specification
label located on the lower left hand side of the unit). Please
have this information available when calling Hatco for service
assistance.
Model No. ________________________________________
Serial No. _________________________________________
Voltage ___________________________________________
Date of Purchase ___________________________________
Register your unit!
Completing online warranty registration will prevent delay in
obtaining warranty coverage. Access the Hatco website at
www.hatcocorp.com, select the Support pull-down menu,
and click on “Warranty”.
Business
Hours: 7:00  to 5:00  Monday–Friday,
Central Time (CT)
(Summer Hours — June to September:
7:00  to 5:00  Monday–Thursday
7:00  to 4:00  Friday)
Telephone: 800-558-0607; 414-671-6350
E-mail: support@hatcocorp.com
24 Hour 7 Day Parts and Service
Assistance available in the United States
and Canada by calling 800-558-0607.
Additional information can be found by visiting our web site at
www.hatcocorp.com.
CONTENTS
