Model Voltage Watts Amps Plug Configuration Shipping Weight
TPT-120 (US) 120 1800 15.0 NEMA 5-15P 15 lbs. (7 kg)
TPT-120 (CAN) 120 1440 12 NEMA 5-15P 15 lbs. (7 kg)
TPT-208 208 2700 13.0 NEMA 6-15P* 15 lbs. (7 kg)
TPT-240 240 2700 11.3 NEMA 6-15P 15 lbs. (7 kg)
Form No. TPTM-0712
5
SPECIFICATIONS
Dimensions—TPT Series
12-3/8"
(313 mm)
13-5/8"
(346 mm)
8-1/16"
(204 mm)
12"
(304 mm)
8-1/16"
(204 mm)
TPT Series Slot Openings = 1-1/4" W x 5-1/2" D x 4-1/2" H (32 x 140 x114 mm)
Front View Side View
Plug Configurations
Units are supplied from the factory with an electrical cord and
plug installed. Plugs are supplied according to the application.
ELECTRIC SHOCK HAZARD: Plug unit into a properly
grounded electrical receptacle of correct voltage, size, and
plug configuration. If plug and receptacle do not match,
contact a qualified electrician to determine and install
proper voltage and size electrical receptacle.
NOTE: Specification label located on the bottom of the unit.
See label for serial number and verification of unit
electrical information.
Plug Configurations
NOTE: Receptacle not supplied by Hatco.
NEMA 5-15P NEMA 6-15P
NEMA 6-20P
Electrical Rating Chart
* NEMA 6-20P for Canada.
