208 2420344510 E 11.11 AUS
Telescopic handlers
H
- Lubrication and maintenance
13 - Every 400 h hours of operation
13.1 - BUCKET TEETH (OPTION)
The bucket teeth are considered to be worn and must be replaced when :
• the useful length has reached 50 % of its initial length. i.e. when the total length of the tooth has lost 28
% (Total initial length = 127 mm ; Total remaining length = 91 mm).
To change the teeth :
• Knock out the flexible block key using a punch.
• Install a new tooth using a new key which must be inserted from above.
Under normal conditions of use, the bucket teeth must be replaced every 400 h.
Check the condition of the bucket teeth regularly : corner teeth and central teeth. The corner teeth are
placed to protect the sides of the bucket and wear more quickly than the central teeth.
It is forbidden to mount a tooth using an old key.
A broken tooth holder must be replaced rapidly so as not to cause premature wear on the remaining teeth.
