Haulotte HA18PX User Manual

70 24203 3237 0 E 09 07 EN
E - Driving
12 to 26m engine-powered articulated lifts
2.2.3 - Upper console controls
Refer to the corresponding operations to test the controls in the order mentioned
( Section E 3.3- Operations from the platform).
Tests from the upper console HA12PX (HA33JRT)
Tests from the upper console HA16X
Step Control
1 Engine start-up selector P61
2 Front axle direction selector ( P52 ) and movement joystick ( P52 )
3
Movements :
• Jib elevation/lowering ( P63 ) and movement joystick P52
• Platform rotation ( P64 ) and movement joystick P52
• Platform compensation ( P65 ) and movement joystick P52
• Arm elevation/lowering ( P66 ) and movement joystick P52
• Boom elevation/lowering ( P67 ) and movement joystick P52
• Boom telescope extention/retraction ( P68 ) and movement joystick P52
• Turntable rotation ( P69 ) and movement joystick P52
4
Driving speed selector :
• Slow speed selector ( P57 ) and movement joystick P52
• Medium speed selector ( P58 ) and movement joystick P52
• Fast speed selector ( P59 ) and movement joystick P52
5 Differential blocking selector P60
6 Horn selector P62
Step Control
1 Engine start-up selector P42
2 Driving P33
3 Platform rotation selector P38
4
Movements :
• Lifting/lowering of arm P50
• Lifting / lowering of boom P49
• Boom telescope extension/retraction P54
• Turntable rotation P49
• Platform compensation P40
5
Driving speed selector :
• Slow speed selector ( P71 ) and movement joystick P33
• Medium speed selector ( P71 ) and movement joystick P33
• Fast speed selector ( P71 ) and movement joystick P33
6 Differential blocking selector P35

Haulotte HA18PX Specifications

General

Platform Capacity	230 kg
Turntable Rotation	360° continuous
Drive Speed	5.5 km/h
Power Source	Diesel
Overall Width	2.3 m
Platform Size	1.8 m x 0.8 m
Capacity	230 kg
Platform Length	1.8 m
Platform Width	0.8 m
Travel Speed	5.5 km/h
