Even Cut Edger Parts List
Item Part No. Description Qty Item Part No. Description Qty
1 200-055 Hexagon Bolt M6x50 GB5782 1 40 800-018 Front Axle 1
2 200-042 Plain Washer 6 GB96 1 41 800-019 Front Wheel Spacer 1
3 800-001 Throttle Control 1 42 200-006 Nylon Nut M10 GB889 3
4 800-002 Handle Weldment 1 43 200-087 Hexagon Bolt M5x16 GB5783 3
5 200-009 Nylon Nut M6 GB889 12 44 200-184 Lock Washer 5 GB93-87 3
6 200-030 Nylon Nut M8 GB889 13 45 200-138 Plain Washer 5 GB95 3
7 200-021 Plain Washer 8 GB95 5 46 800-020 Drive Belt (4L-300) 1
8 300-070 Compression Spring 1 47 800-021 Guard,Engine Pulley 1
9 200-181 Cotter Pin 3.2*16 GB91 2 48 800-022 Cutterhead Pulley 1
10 200-010 Plain Washer 10 GB95 3 49 200-047 Snap Ring 16 GB894.1-86 2
11 800-003 Lever,Clutch & Depth 1 50 200-113 Bearing 99502 2
12 200-082 Hexagon Bolt M8x45 GB5783 1 51 800-023 Shaft 1
13 800-004 Grip 1 52 200-026 Grease Fitting M6 GB1152-89 2
14 800-005 Rod,Cluth & Depth 1 53 800-024 Mandrel,Head 1
15 800-006 Swivel 1 54 800-025 Cutting Blade 1
16 800-007 Cross Brace For Handle 1 55 200-127 Plain Washer 12 GB5287 2
17 800-008 Crank Frame 1 56 200-076 Nut 1/2-20 1
18 200-049 Hexagon Bolt M8x40 GB5783 4 57 800-026 Spring,Head Recoil 1
19 200-048 Hexagon Bolt M8x20 GB5783 4 58 800-027 Cup 1
20 800-009 Wheel Cover 2 59 800-028 Pivot Hub 1
21 200-036 Hexagon Bolt M6x20 GB5783 4 60 800-029 Body,Cutterhead 1
22 800-010 Rear Wheel 2 61 200-185 Roll Pin 8*40 1
23 200-071 Plain Washer 12 GB95 2 62 200-186 Roll Pin 8*32 1
24 200-182 Snap Ring 12 GB894.1-86 2 63 800-030 Lever, Angle Shifting 1
25 800-011 Rear Axel 1 64 800-031 Torsion Spring 1
26 Engine 1 65 200-003 Hexagon Bolt M10x25 GB5783 1
27 200-119 Hexagon Bolt M8x25 GB5783 1 66 800-032 Brace Cutterhead 1
800-043 Hexagon Bolt 5/16-24 for 3.5 hp 1 67 200-187 Hexagon Bolt M10x80 GB5782 1
28 200-024 Lock Washer 8 GB93-87 1 68 800-033 Blade Guard Main 1
29 200-098 Plain Washer 8 GB96 1 69 200-120 Hexagon Bolt M6x16 GB5783 2
30 800-012 Engine Pulley 1 70 800-034 Deflector,Debris Sweep 1
800-012A Engine Pulley for 3.5 hp B&S 1 71 800-035 Safety Flap 1
31 800-013 Key 5*5*35 1 72 800-036 Immobility Board 1
800-013A Key for 3.5 hp B&S 1 73 200-121 Hexagon Bolt M6X20GB5783 1
32 200-083 Bolt Screws M8x8 GB79-85 1 800-045 Hexagon Bolt M6X*20Left 1
33 800-014 Bracket,Engine Pulley Guard 1 74 800-037 Caution Decal 1
34 800-015 Cutterhead Pulley Guard 1 75 800-038 Disengage Decal 1
35 200-085 Hexagon Bolt M8x35 GB5783 4 76 800-039 Starting Engine Decal 2
36 800-016 Deck 1 77 800-040 Name Plate Decal 1
37 200-007 Nylon Nut M12 GB889 1 78 800-041 Blade Angle Decal 1
38 200-183 Nut M12 GB6170 1 79 800-042 Danger Decal 1
39 800-017 Front Wheel 2
