7/64
Hawa Concepta 25/30
2 Product information
Intended use
Pivot/slide-in hardware for wooden pocket doors for cabinet or wall recesses.
Intended place of use
Dry areas and interior areas where condensation may occur, e.g. in kitchens or bathrooms, but without any significant
chloride contamination.
Technical Data
LGA certificates are available for downloading at www.hawa.ch
Quick and reliable planning with the online calculation tool: www.concepta.hawa.com
Article number
Articles are identified by a 5-digit number.
General notes
The document «Safety Notes» (22991) is an integral part of these planning and assembly instructions.
The operating instructions, the planning and assembly instructions and the document «Safety note(22991) must be handed over
to the end user.
Metric measurements apply - those in inches are for information only.
Retain the instructions. Replacements available from www.hawa.ch.
Risk and residual risk
When using Hawa Concepta 25/30 to conceal electrical appliances please pay attention to the safety notes issued by the
manufacturer (heat accumulation). If necessary, use an automatic shutoff device (e.g. Safety Box, www.halemeier.de).
Disposal
Materials, accessories and packaging should be recycled in an environmentally friendly manner.
3 Safety instructions
CAUTION
Moving parts can crush fingers.
Do not touch moving parts!
Hawa Concepta 25 Hawa Concepta 30
Maximum door weight 25 kg (55 lbs.)
Maximum door weight 30 kg
(66 lbs)
Door width 300 – 750 mm (11 "– 2’5 ")
Door width 300 – 900 mm
(11 "– 2’11 ")
Door height 12501850 mm (4’1 "– 6’0 ")
Door height 18512300 mm
(6’0 "–7’6 ")
Door thickness 1950 mm ( "– 1 ")
Door thickness 1950 mm
( "– 1 ")
Sets can be used on the left and right.
Use the straightening fitting for stabilizing sliding doors.
For maximum door size / weight ratios, see table on page 21.
Maximum permissible deflection of the hardware assembly face and door ± 2 mm ( ").
13
16
-----
17
32
-----
13
16
-----
7
16
-----
7
32
-----
27
32
-----
7
8
--
9
16
-----
3
4
--
31
32
-----
3
4
--
31
32
-----
3
32
-----
