47
Battery Mat. No
SAP No
Thermostat
assembly
Mat. No
SAP No
Amount of
Thermostats
Colour NCC/ NOC Switching
range
Buttonthermostat 70°C
F 20/7 H1C T-E2 334 9007 3001
2314837
Temperature sensor 308 9946 191
2300329
1x Thermostat Yellow NOC 70°C ± 1.7°C
F 20/40 H1C T 334 9040 9206
2316002
Temperature sensor 308 994 6192
2300345
1x Thermostat Yellow NOC 70°C ± 1.7°C
F 20/27 H1C T70 334 9027 910
2315599
Temperature sensor 308 9946 200
2300394
1x Thermostat Yellow NOC 70°C ± 1.7°C
F 20/25 H1C T ELC 334 9025 910
2300418
Temperature sensor 308 9946 202
2300418
1x Thermostat Yellow NOC 70°C ± 1.7°C
F 20/40 H1C T2 (P) 334 9040 9201
2315955
Temperature sensor 308 9946 204
2300434
2x Thermostat Yellow NOC 70°C ± 1.7°C
F 20/17 H1C T-2 334 9017 950
2315088
Temperature sensor 308 9946 215
2300467
1x Thermostat Yellow NOC 70°C ± 1.7°C
20/FP 25 H1C T-R 334 9025 950
2315396
Temperature sensor 308 9946 225
2300475
1x Thermostat Yellow NOC 70°C ± 1.7°C
20/FP38 H1C T-R
with Connector
334 9038 9011
2315785
Temperature sensor 308 9946 226
2300483
1x Thermostat Yellow NOC 70°C ± 1.7°C
20/FP38 H1C T-R
without Connector
334 9038 901
2315769
Temperature sensor 308 9946 2262
2300515
1x Thermostat Yellow NOC 70°C ± 1.7°C
20/FP 38 H1C T2-R 334 9038 9010
2315777
Temperature sensor 308 9946 227
2300523
2x Thermostat Yellow NOC 70°C ± 1.7°C
F 20/44 H1C T 334 9045 920
2316198
Temperature sensor 308 9946 269
2300791
1x Thermostat Yellow NOC 70°C ± 1.7°C
F20/40 H1 E1 T 334 3409 1301
2314594
Temperature sensor 308 9946 351
2300961
1x Thermostat Red NOC 70°C ± 1.7°C
F20/27 H1C MT 334 9027 700
2315493
Temperature sensor 308 9946 359
2301033
1x Thermostat Yellow NOC 70°C ± 1.7°C
F 20/27 H1C M1 T 334 9027 7000
2315509
Temperature sensor 308 9946 359
2301033
1x Thermostat Yellow NOC 70°C ± 1.7°C
F 20/4 H1C T 334 9004 920
2314789
Temperature sensor -
2818252
1x Thermostat Yellow NOC 70°C ± 1.7°C
F20/44 H1C WT 334 9045 9202
2316221
Temperature sensor -
2819435
1x Thermostat Yellow NOC 70°C ± 1.7°C
F20/17 H1C T 334 9017 960
2315096
Temperature sensor 308 9946 199
2821905
1x Thermostat Yellow NOC 70°C ± 1.7°C
Buttonthermostat 60°C
F19/25 H1 T2 3343258140
2314456
Temperature sensor 308 9946 354
2300994
2x Thermostat Green NOC 60°C ± 1.7°C
F 20/40 H1C T2-1 334 9040 9202
2315963
Temperature sensor 308 9946 355
2301009
2x Thermostat Green NOC 60°C ± 1.7°C
F20/40 H1C T2 334 9040 9205
2315996
Temperature sensor -
2809909
2x Thermostat Geen NOC 60°C ± 1.7°C
Buttonthermostat 60+70°C
F 19/25 H1C T2 ELC 334 9025 820
2315266
Temperature sensor 308 9946 352
2300978
1xThermostat(60°)
1xThermostat(70°)
Green
Yellow
NOC
NOC
60°C ± 1.7°C
70°C ± 1.7°C
F 20/25 H1C T2 ELC 334 9025 920
2315355
Temperature sensor 308 9946 352
2300978
1xThermostat(60°)
1xThermostat(70°)
Green
Yellow
NOC
NOC
60°C ± 1.7°C
70°C ± 1.7°C
F 20/40 H1C T3 334 9040 9209
2316035
Temperature sensor 308 9946 445
231041
1xThermostat(60°)
1xThermostat(70°)
1xYSI-NTC
Resistor.
Green
Yellow
Black
NOC
NOC
60°C ± 1.7°C
70°C ± 1.7°C
F 20/27 H1C T2 334 9027 940
2315647
Temperature sensor -
4448191
1xThermostat(60°)
1xThermostat(70°) Yellow
NOC
NOC
60°C ± 1.7°C
70°C ± 1.7°C
NTC-Thermistor
F 20/40 H1C WT 334 9040 930
2316043
Temperature sensor 308 9946 274
2300831
NTC-Thermistor Red NOC 33 KOHM
F20/44 H1C WT 334 9045 9202
2316221
Temperature sensor -
2819443
NTC-Thermistor Red NOC 33 KOHM
APPENDIX 4: TEMPERATURE HARNESSES
