IMPORTANT SAFETY INSTRUCTIONS
SAFETY WARNING: Do not open. Lamp has no user serviceable parts inside. Improper installation
may result in death or serious injury to bathers or service personnel or others by way of electric
shock. Disconnect electrical power before installing or servicing this equipment. Read and follow all
instructions. This product to be installed by qualified personnel only.
Model Input (Volts, Amps, Watts)
BPCUS11120 120 VAC 60 Hz, 0.24A, 28.5W
IMPORTANT WIRING CHECKLIST
Do not skip any steps in this or any section of the manual.
The above safety warnings and the complete installation instructions in this manual have
been read and followed.
The cord length has not been extended beyond the guidelines in this manual.
The cord jacket is not damaged, cut or spliced except as noted below.
Extensions or splices to the cord are only made in a safety listed Pool/Spa junction box
or junction box transformer system.
The light fixture strain relief is firmly secured.
The luminaire is firmly secured to the pool wall and cannot be removed without removal
of the strain relief.
The luminaire has been installed by qualified personnel in compliance with the National
Electrical Code (NEC) or Canadian Electric Code (CE Code) and any applicable local
codes and/or regulations.
Bonding wire is secure and properly attached to bonding system.
Ground is secure and properly attached.
Power is shut off.
LEAVE THESE INSTRUCTIONS WITH PROPERTY OWNER
1
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
