Introduction
The Hayward
®
BPCUS11120 is a UL Listed Color LED replacement lamp designed for use in com-
patible light fixtures listed below. Using up to 86% less energy and lasting up to 10x longer than
conventional 300 watt incandescent and halogen lamps, the BPCUS11120 makes an efficient and
long lasting replacement for your existing pool light. When used in standalone mode, lamp colors are
controlled by turning on/off power repeatedly. When used with a Hayward automation control, colors
can be programmed with schedules and easily changed and saved with a button.
Pool & Spa Light Housing Compatibility
Replacement LED in-ground pool lamps must be installed in a compatible Nationally Recognized Test-
ing Laboratory (NRTL) approved pool light fixture or housing. Compatible NRTL light fixtures include:
• Hayward
®
Astrolite
™
SP058 Series
• Pentair
®
Amerlite 784 Series
• Swimquip 05086 Series
Hayward Pool Control Compatibiltiy
The Hayward
®
BPCUS11120 is compatible with the following Hayward Pool controls:
• OmniLogic
• OmniHub
• Pro Logic
• ColorLogic Light Controller
Installation
Before You Begin
Before attempting to install, confirm that you have a compatible light fixture. Disconnect power to
the pool light at the main panel before attempting to service the lamp. Refer to the original manu-
facturer’s pool light installation manual before proceeding. This service should be performed by a
qualified individual.
Because the BPCUS11120 must be kept dry, be sure to have a new replacement gasket for your
light fixture before starting the installation. Do not re-use the existing gasket as a leak inside the
fixture could cause serious injury or death due to electrical shock.
Safety precautions and Installation notes
• Do not open, service or tamper with any internal component of the BPCUS11120 LED under-
water pool lamp.
• Do not directly expose or immerse the lamp in water before installation.
• During removal of the old lamp and installation of the BPCUS11120, keep the inside of the
light housing dry.
• Handle the lamp with care. Be careful not to drop the unit or permanent damage can occur.
• The BPCUS11120 can not be used with dimmers or dimming systems.
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
2
