Introduction
Before You Begin
What’s Included
Before attempting to install the ECOMMAND 4 system, check that the following components have been
included in the package:
ECOMMAND 4 Electronics Unit
(3) Temperature sensors with 15 ft. (5m) cable, hose clamp
(2) Goldline GVA-24 actuators (HPC-4-ACT, HPC-4-ACT-RC only)
(1) Goldline AQL2-BASE-RF/AQL2-SS-RF remote control (HPC-4-RC, HPC-4-ACT-RC only)
What’s NOT Included
Some of the additional items that you may need to complete an installation include:
Circuit breakers
None are included with control—see page 6 and inside of door for suitable breakers
Wire
4-conductor cable (electronics unit to external chlorination)
Wire/conduit for 100A service from main panel to ECOMMAND 4
Wire/conduit for filter pump and other high voltage loads
Wire for bonding
Miscellaneous
Mounting hardware (screws, etc.) for mounting ECOMMAND 4
Valves (use standard Hayward, Pentair/Compool, or Jandy valves)
Additional valve actuators
Accessory Products - Order Separately
AQL2-SS-RF Wireless Spa Side Remote Control (Included with HPC-4-RC, HPC-4-ACT-RC)
AQL2-BASE-RF Base Station required if using AQL2-SS-RF (Included with HPC-4-RC, HPC-4-ACT-RC)
AQL-DIM Light Dimmer Relay
GVA-24 Valve Actuator
V&A-xx Valve & Actuator (xx=1P (1.5” pos. seal), -2P (2” pos. seal), (Included with HPC-4-ACT,
HPC-4-ACT-RC)
1
High Voltage pool equipment
Low voltage wiring (temperature sen-
sors, heater, etc.)
4. ECOMMAND 4 configuration (page 14)
5. System Startup and checkout (page 24)
Installation Steps
Details on each installation step are presented on
the following pages:
1. Mounting the equipment (page 2)
ECOMMAND 4 main unit
Temperature sensors
Optional Remote Control
Optional Base Station
Valve actuators (if applicable)
2. Plumbing (page 4)
General Pool Equipment
3. Electrical Wiring (page 6)
Main service
Grounding and bonding
Circuit breakers
ECOMMAND 4 control power
26
