6. APPENDICES (continued)
ECP 06
N Ref. Description N Ref. Description
1 HWX950531145 PC1000 circuit board 20 HWX20003242 Temperature sensor
2 HWX35252208 Grille 21 HWX20003242 Temperature sensor
3 HWX322521062 Rear stiffener 22 HWX20003242 Temperature sensor
4 HWX322521063 Front stiffener 23 HWX35251210
Titanium/PVC
capacitor
5 HWX32025210084 Front ABS panel 24 HWX20041444
Filter (diam. 9.7- diam.
9.7)
6 HWX32025210081 Frame 25 HWX200014068 Capillary connector
7 HWX34012701 Fan blade 26 HWX20002111
Controller protective
cover
8 HWX34013301 Fan motor 27 HWX950531188 7-segment controller
9 HWX32025210083 Left panel 28 HWX322521057 Right panel
10 HWX20003603 Low pressure switch 29 HWX32009220054 Protection cover
11 HWX322521061 Motor bracket 30 HWX322521064 Electrical box cover
12 HWX322521059 Centre wall 31 HWX200011006 Compressor
13 HWX20013605 High pressure switch 32 HWX322521006 Electrical box
14 HWX322522016 Top ABS cover 33 HWX200037006
230V~/12V~
transformer
15 HWX20011418 4-way valve 34 HWX40003901 5-point terminal block
16 HWX200014153 Schräder valve 35 HWX20003506 Fan capacitor 2μF
17 HWX20003242 Temperature sensor 36 HWX20003909 2-point terminal block
18 HWX40001230 Coil 37 HWX20003504
Compressor capacitor
35μF
19 HWX200036005 Flow detector 38 HWX20009910 Capillary
To Next Page
