6. APPENDICES (continued)
ECP 08
N Ref. Description N Ref. Description
1 HWX20003501 Fan capacitor 3μF 21 HWX20003242 Temperature sensor
2 HWX35122213 Grille 22 HWX32008120005
Titanium/PVC
capacitor
3 HWX32012210240 Front ABS panel 23 HWX20003242 Temperature sensor
4 HWX321221175 Front stiffener 24 HWX20041445 )LOWHUĭĭ
5 HWX321221018 Rear stiffener 25 HWX20002111
Controller protective
cover
6 HWX35002701 Fan blade 26 HWX950531188 7-segment controller
7 HWX321221174 Motor bracket 27 HWX32009220054 Protection cover
8 HWX34043301 Fan motor 28 HWX32012210238 Right panel
9 HWX32012210238 Left panel 29 HWX200011135 Compressor
10 HWX321221173 Centre wall 30 HWX321221019 Electrical box cover
11 HWX20013605 High pressure switch 31 HWX32012210237 Frame
12 HWX20003603 Low pressure switch 32 HWX321221176 Electrical box
13 HWX32012210241 Top ABS cover 33 HWX20003619 Relay
14 HWX20011418 4-way valve 34 HWX20003909 2-point terminal block
15 HWX20041446
Filter (diam. 9.7 -
diam. 3.4)
35 HWX950531145 PC1000 circuit board
16 HWX200014153 Schräder valve 36 HWX40003901 5-point terminal block
17 HWX34061204 Coil 37 HWX200037006
230V~/12V~
transformer
18 HWX200036005 Flow detector 38 HWX20003510
Compressor capacitor
60μF
19 HWX20003242 Temperature sensor 39 HWX20009909 Capillary
20 HWX20003242 Temperature sensor
