5
2. TECHNICAL SPECIFICATIONS
2.1 Heat pump technical data
Models
EASYTEMP
FULL INVERTER
ECPI15MA ECPI20MA ECPI30MA ECPI40MA
Supply voltage V
220V-240V /1ph/50Hz
Refrigerant / R32
Load kg 0.350 0.430 0.480 0.650
Mass in teqCO
2
/ 0.24 0.29 0.32 0.44
Leak check frequency / No specific frequency, but an annual check is recommended
Min--Max heating capacity
(a)
kW 1.62--7.33 2.18--8.97 1.97--11.66 2.85--17.06
Min--Max electric input power
(a)
kW 0.15--1.17 0.17--1.54 0.16--1.99 0.26--3.13
Min--Max continuous current rating
(a)
A 1.15--5.32 1.27--6.91 1.08--8.96 1.41--13.69
Max--Min continuous power (COP)
(a)
/ 11.04--6.30 12.77--5.81 12.57--5.84 11.08--5.45
Min--Max heating capacity
(b)
kW 1.44--5.36 1.58--6.94 1.79--8.62 2.74--13.08
Min--Max electric input power
(b)
kW 0.24--1.14 0.27--1.53 0.290--1.90 0.428--2.97
Max--Min continuous power (COP)
(b)
/ 5.98--4.69 5.82--4.53 6.17--4.52 6.40--4.40
Maximum continuous current A 6.4 8.4 10.9 16.6
Fuse rating aM 8 10 16 20
Circuit-breaker curve D D 8 10 16 20
Starting current A < maximum continuous current
Hydraulic connection mm 50 mm
Nominal water flow
(a)
m
3
/h 3.10 3.80 4.90 7.30
Max. loss of head on water kPa 2.3 2.9 6.4 6.7
Compressor / Mitsubishi DC Inverter
Highly DC
Inverter
Type / Twin rotary Twin rotary
Quantity / 1
Coil resistance at 20°C Ohm 1.91 0.788
Fan / Axial
Quantity 1
Diameter mm 405 510
Number of blades / 3
Motor / DC Inverter
Quantity / 1
Rotation speed rpm 600--700 600--800 850--950 600--850
Silent mode speed rpm 400 400 400 300
Sound pressure level at 1 metre dB(A) 46,2 44,9 48,8 45,7
Sound pressure level at 10 metres dB(A) 28,8 27,5 31,4 28,8
Unit's net dimensions (L-W-H) mm 1040/425/615
1130/460/780
Weight kg 42 45 46 60
(a) Dry air 27°C - Relative humidity 78% - Water inlet temperature 26°C.
(b) Dry air 15°C - Relative humidity 71% - Water inlet temperature 26°C
