Hayward HP50A - Page 5

ABG Heat Pump: Specifications
HP50A/HP50HA - Specifications
Heating Capacity
14.7kW
50,000 BTU/h
Refrigerant Type
R-410A
Heating Power Input 2.68kW
Running Current 12A
Power Supply 208-230VAC/60Hz
Compressor Quantity 1
Compressor Rotary
Fan Quantity 1
Fan Power Input 120W
Fan Rotate Speed 850RPM
Fan Orientation Horizontal
Noise (at 1 meter) 54 dB(A)
Water Connection 1.5 inch
Water Flow Volume US 20GPM
Water Pressure Drop (max) 1.5 psi
Unit Net Dimensions (L/W/H) 41.5"x16.5"x25.6"
Unit Shipping Dimensions (L/W/H) 43.7"x18.5"x26.4"
Shipping Weight 128lbs
Heating: Ambient temp (DB/WB): 75ºF (24ºC) / 66ºF (19ºC)
Water temp (in/out): 79ºF (26ºC) / 82ºF (28ºC)
5
