Hayward MAGIC CLEAN - Parts Listing

Above-Ground Automatic Pool Cleaner _________________
Replacement Parts (cont.)
Parts Listing
Ref. No. Part No. Description Ctn. Qty. No. Req’d
1 AEXV464 Head Assembly (includes Head, Eyes & Antennae) 10 1
2a AEXV457OR Shell, Magic Clean * 1
2b AEXV457YL Shell, AquaCritter * 1
2c AEXV457SD Head Assembly for Scuba * 1
2d AEXV457W Head Assembly for Whaly including Tail * 1
2e AEXV457WT Tail Assembly for Whaly * 1
3 AEXV513BK Screen, Black 10 1
4 AEXV443 Magic Clean Spots, 4 lg. & 2 sm. 10 1
5 AEXV070 Cone Gear * 1
6 AEXV309 Intermediate Gear Shaft * 1
7 AEXV301 Intermediate Gear 25 1
8 AEXV068 Spindle Gear Screw * 1
9 AEXV303 Spindle Gear 25 1
10 AEXV066A Spindle Gear Bushing 25 1
11 AEXV306 Cone Gear Bushing 50 1
12 AEXV060WH Upper Middle Body * 1
13 AEXV065P Lower / Upper Body Screw (6 pack) * 1
14 AEXV064A Medium Turbine Drive Gear 25 1
15 AEXV062C Medium Turbine 25 1
16 AEXV009 Medium Turbine Case with Axle 25 1
17 AEXV055P Turbine Bearings (2) 50 1
18 AEXV518P Gear Box 10 1
19 AEXV050CWH Lower Middle Body * 1
20 AEXV525A Base Plate Assembly 5 1
21 AEXV551P Wheel Kit (6 wheels, axles) 25 1
22 AEXV458 Ring, Black 5 1
23 AEXV057P Middle Body Screw (6 pack) * 1
24 AEXV313 Lower Body Screw * 1
25 AEXV030A Lower Body (fixed throat) 10 1
26 AEXV442 Flap Kit, White (2 flaps, front & rear) 25 1
27 AEXV417WHP Pod Kit 25 1
28 AEXV015P Pod Screw Kit (2 hex head screws & 2 washers) 50 1
29 AEXV016P Pod Plug (6 pack) 50 1
30 AEXV552WHP Wing Kit, White 50 1
31 AEXV014SP Slotted Santoprene Shoes (4 pack) 50 1
32 AEXV304A Bottom Plate 25 1
33 AEXV512A Nozzle * 1
*Special order
