Hayward PoolVac V-Flex - Hose Length and Flow Gauge Setup

7
+2
Step 2
Pull hose to farthest point of the pool + 2 extra hose sections.
Step 3
Fill hose completely with water.
Insert Flow Gauge into the leader
hose. Attach the C-Clip of the
gauge onto the 1st hose section.
Make sure the Flow Gauge is under water.
FLOW GAUGE
C-CLIP
LEADER HOSE
FIRST HOSE
SECTION
TO SKIMMER
OR VAC-LOCK
