Controls
Main Switch
AUTO: For normal operation, the Main Switch should be left in the AUTO position. In this posi-
tion the SwimPure Plus will produce chlorine according to the "Desired Output %" adjustment
setting for the entire filtering/pumping cycle.
SUPER CHLORINATE: When you have an abnormally high bather load, a large amount of rain,
a cloudy water condition, or any other condition which needs a large amount of purification
to be introduced, put the Main Switch in the SUPER CHLORINATE position. This electronically
“super chlorinates” (shocks) the water for 24 hours (filter pump must be on during this time) or
until the power has been turned off, whichever comes first. At the end of the super chlorinate
time, be sure to put the switch back into the AUTO position.
OFF: The OFF position prevents the SwimPure Plus from energizing the electrolytic cell. In
this position there is no chlorine generation. NOTE: To service any of the pool equipment or
the SwimPure Plus, turn the power off at the circuit breaker.
Indicator LED's
POWER When illuminated, the SwimPure Plus has input power.
GENERATING This LED is on steady during normal operation. When flashing, the pool water
is too hot or cold to operate.
SUPER CHLORINATE Illuminates during super-chlorination. See description above.
REMOTELY CONTROLLED When illuminated, indicates that a remote pool automation control
(Hayward Pro Logic, Pentair Intellitouch, Polaris Eos, etc.) is controlling the SwimPure Plus--the
main switch and "Desired Output %" adjustment are inactive. When flashing, the Pro Logic,
Intellitouch or Eos is in SERVICE or TIME-OUT mode and the Main Switch and "Desired Output
%" adjustment are active.
NO FLOW When illuminated, the flow switch has detected no water flowing and the SwimPure
Plus has stopped generating chlorine. A flashing LED indicates a 15-60 second time delay
period.
CHECK SALT When flashing, the salt level is low (below 2700 ppm) and SwimPure Plus is
generating at low efficiency. When illuminated steady, the salt level is too low and SwimPure
Plus has shut down. Before adding large quantities of salt, it is advisable to have your salt
level professionally checked.
HIGH SALT When illuminated, the salt level is too high and SwimPure Plus has shut down.
INSPECT CELL A flashing indicator signifies that either the cell efficiency is reduced or that it
is time for regularly scheduled cell inspection. In either case, inspect cell and clean if neces-
sary. When illuminated steady, cell efficiency is greatly reduced and the SwimPure Plus
has
stopped producing chlorine. Inspect, clean or replace if necessary.
7
USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
