6.6. Configuration Menu
Buttons
Screen Used Comments
1. < > Press & hold < and > buttons for several seconds to
unlock Configuration Menu
2.
< > Use > to enter Configuration Menu
3.
4.
+ - Select language for all displayed messages
< > Move to next menu item
5.
+ - Use + to change clock setting
< > Use > if clock is correct
6.
+ - Adjust day/time setting
< > Move to next selection, then to next menu item
7.
+ - Select whether to display speed in rpm (Revolutions
per Minute) or % of full speed
< > Move to next menu item
8.
+ - Set maximum running speed of pump
< > Move to next menu item
9.
+ - Set minimum running speed of pump
< > Move to next menu item
10.
+ - Select pump prime duration
< > Move to next menu item
Note: User may set the pump to prime at the maximum allowed speed for 0-15 minutes in 30 second increments.
11.
+ - Select Stand Alone or Relay Control
< > Move to next menu item
Note: See section 5.3 for more detail.
12.
+ - Set SVRS Restart to Automatic or Manual
< > Move to next menu item
Note: For SVRS pump models, the SVRS feature may be set to restart automatically or manually after a trip event
occurs. When set to Automatic, the pump will resume normal operation after 15 minutes, or the user may manually
restart the pump prior to the automatic restart by pressing the Stop/Resume button. When set to Manual, the pump
will resume normal operation ONLY after the user presses the Stop/Resume button.
Configuration Menu
press > to enter
Set Day and Time
Thursday 1:27p
Speed Selection
rpm
Max allowed spee
3450 (600-3450rpm)
Min allowed spee
600 (600-3450rpm)
Prime Duration
8:00 minutes
Remote Control Mode
Stand Alone
Configuration Menu
Locked
Display Language
English
Press +/- to change
or > view next item
SVRS Restart
Automatic
Time: Th 1:27PM
+ change or > skip
