USE ONLY HAYWARD GENUINE REPLACEMENT PARTS
Page 31 of 36 2.70 THP VS Pump Family IS3206VSP3 Rev-B
Ref.
No.
Part No. Description Qty.
11 SPX3021R Impeller Ring 1
12 SPX3220C Impeller with Impeller Screw 1
13A SPX3200SA Shaft Seal Assembly 1
13B SPX4000SAV Shaft Seal Assembly (Viton) 1
14 SPX3200T Housing O-Ring 1
15 SPX3200E Seal Plate 1
16 SPX3200Z211 Housing Insert/Seal Plate Spacer Kit 1
17 SPX3200Z3 Housing Bolt 1
18 SPX3200Z5 Motor Bolt 1
19 SPX4000FG Drain Plug with O-Ring 1
20 SPX3200GA Motor Support 1
21 SPX3200W
F
Optional Riser Base aligns with Pentair® WhisperFlo® pump*
)
1
22 SPX3200
Q
Motor Support Adapter 1
23 SPX3400DR4 Motor Drive Display Cover (Cover only) 1
24 SPX3200LCD Digital Control Interface Assembly 1
25A SPX3206Z1VSPE Power End Assembly, Non-SVRS (Includes #7-15, 2 ea. #16-17, #18, #24 &
Motor Assembly)
1
25B SPX3206Z1VSPEVR Power End Assembly, SVRS (Includes #7-15, 2 ea. #16-17, #18, #24 & Motor
Assembly)
1
- SPX3400DRKIT Wall Mount Kit 1
- SPX3200DRCC Comm Cable Kit 1
* WhisperFlo is a registered trademark of Pentair Aquatic Systems, which is used herein for identification purposes
only. This is a retrofit base for existing WhisperFlo pump installations. Pentair Aquatic Systems is not affiliated with
Hayward Pool Products.
