HBK U3 - Scope of Supply; Included Components; Optional Accessories

U3
SCOPE OF SUPPLY
6
3 SCOPE OF SUPPLY
S 1 U3 force transducer
S 1 U3 Mounting Instructions
S Test report
Accessories (not included in the scope of supply)
S 'Complete adapter' for knuckle eye mounting:
0.5-10 kN Adapter with four M5x12 and four M5x16 screws
Order no. 2-9289.1956
20 kN Adapter with four M10x25 and four M10x30 screws
Order no. 2-9289.1957
50 kN Adapter with eight M10x25 and eight M10x30 screws
Order no. 2-9289.1958
100 kN Adapter with eight M10x25 and eight M10x30 screws each
Property class 12.9. galvanized Order no. 2-9289.2280
S Knuckle eye ZGUW for:
0.5-10 kN Order no. 1-U2A/1 t/ZGUW
20 kN Order no. 1-U2A/2 t/ZGUW
50 kN Order no. 1-U2A/5 t/ZGUW
100 kN Order no. 1-Z4/100 kN/ZGUW
