1. Shock Lower Mount Ball 4.8
2. Shock Bottom Mount
3. Shock Spring Retainer(bottom)
4. Shock Spring
5. Shock Body Bush
11. E-Clip(2mm)
12. Shock Piston
13. Shock Seal(Large)
14. Shock Cap
15. Shock Upper Mount
6. Shock Seal(small)
7. Shock Spring Retainer(upper)
8. Shock Adjustable Clasp
9. Shock Body
10. Shock Shaft
1.Front/rear Diff. Outdrive(L/R)
2.Ball Bearing 10*15*4
3.Round Head Self Tapping Screw
2*9
4.Diff. Main Gear
5.Diff. Seal
6.Diff. Shim-Large
7.Diff. Pin 2*10
8.Diff. Bevel Gear(Large)
9. Diff. Shim-Small
10.Diff. Bevel Gear(Small)
11.Diff. Small Bevel Gear Open
Pin
12. E-Clip
13. Diff. Pinion
14. Diff. Pinion Post
15. Ball Bearing 5*11*4
16. Diff. Gear Case
1
2
3
4
5
6
7
8
9
10
11
10
9
10
10
9
11
9
7
6
8
5
12
13
14
15
16
1
2
3
