User's Guide
u Battery Pack
The battery pack is automatically charged when connected to an AC power source and maintains power to the
Notebook PC when AC power is not connected. This allows us moving temporarily between locations. Battery
time varies by usage and by the specifications for this Notebook PC. The battery pack cannot be disassembled
and must be replaced as a single unit through an authorized vendor.
v Battery Lock - Manual
The manual battery lock is used to keep the battery pack secured. Move the manual lock to the unlocked
position to insert or remove the battery pack. Move the manual lock to the locked position after inserting the
battery pack.
w Battery Lock - Spring
The spring battery lock is used to keep the battery pack secured. When the battery pack is inserted, it will
automatically lock. To remove the battery pack, this spring lock must be held in the unlocked position.
x Central Processor Unit (CPU)
Some Notebook PC models feature a socketed-processor design to allow upgrading to faster processors in the
future. Some models feature a ULV design for compactness and may not upgraded. Visit an authorized
services center or retailer for information on upgrades.
Warning :
End-user removal of the CPU or hard disk drive will void the warranty.
Knowing the Parts
2-5
