User's Guide
Important :
Poor handling of the Notebooks PC may damage the hard disk drive. Handle the Notebook PC gently and keep it away
form static electricity and strong vibrations or impact. The hard disk drive is the most delicate component and will likely be
the first or only component that is damaged if the Notebook PC is dropped.
Connections
Note:
The built-in modem and network cannot be installed later as and upgrade. After purchase, modem and/or network can be
installed as a PC card (PCMCIA).
Modem Connection
The telephone wire used to connect the Notebook PC's internal modem should
have either two or four wires (only two wires (telephone line#1) is used by the
modem) and should have an RJ-II connector on both ends. Connect one end to the
modem port and the other end to and an analog telephone wall socket (the ones
found in residential buildings). Once the driver is setup, the modem is ready to use.
Note:
When you are connected to an online service, do not place the Notebook PC in suspend (or sleep mode)or else you will
disconnect the modem connections.
Warning :
Only use analog telephone outlets. The built-in modem does not support the voltage used in digital phone systems. Do
not connect the RJ-11 to digital phone systems found in may commercial buildings or else damage will occur!
Caution :
For electrical safety concerns, only use telephone cables rated 26AWG or higher.
Using the Notebook PC
4-16
