HEADRUSH MX5 - Features; Top Panel Overview

5
Features
Top Panel
1
3
4
5
6
2
1. Display: This full-color multi-touch display shows information relevant to HeadRush MX5’s current operation.
Touch the display (and use the hardware controls) to control the interface. See Operation to learn how it
works.
2. Main Volume: Turn this knob to adjust the volume level of the outputs.
3. Encoder: Turn this encoder to scroll through the available menu options or adjust the parameter values of the
selected field in the display. Push the encoder to confirm your selection.
4. Footswitch Indicators: These lights indicate whether the stomp, rig, or scene assigned to each footswitch is
on (brightly lit) or off (dimly lit).
5. Footswitches: Press these footswitches to activate or deactivate the assigned model or scene, or to load the
assigned rig.
6. Expression Pedal: Use this pedal to adjust the assigned parameter/parameters. See Operation > Hardware
Assign > Expression Pedal for more information.
